浅析山区油气长输管道的本质安全设计2021-03-25

Analysis of intrinsically safe design of long-distance oil and gas pipelines in mountainous terrain

作者单位:1. 中国石油工程建设有限公司西南分公司,2. 中国石油天然气股份有限公司西南管道分公司
中文关键字:油气长输管道;本质安全;选定线;管材;焊接;布管;稳管;监测
英文关键字:Long-distance oil and gas pipeline; Intrinsically safe; Survey and final selection of pipeline route; Pipeline materials; Welding; Pipeline layout; Pipeline stabilizing; Surveillance and monitoring
中文摘要:山区油气长输管道线路大部分处于崇山峻岭之中,山高谷深,多为高陡长坡及深切冲沟,地势险峻;管道所经地区多为石方区,岩石较为破碎,地质情况极为复杂,不同程度伴有次生地质灾害;管道沿线可依托的道路较少,交通条件差,天气情况恶劣。管道在施工建设过程后期及运营过程中,均易受到地质条件、天气情况、管道本体、施工等因素影响而造成安全隐患。针对山区油气长输管道在建设及运营中面临的诸多挑战,从前期选定线、管材性能指标确定、变壁厚焊接、软硬地层交替的处理、山区布管、稳管措施以及运营中的后续监测等方面,论述了保证山区油气长输管道本质安全的对应措施。

英文摘要:

Most of the pipelines in mountainous areas are located in high mountains and deep valleys, mostly with high and steep long slopes and deep gully. The area through which the pipeline passesby is mostly a rocky area, with relatively broken rocks and extremely complex geological conditions, accompanied by secondary geological hazards to varying degrees. There are few access roads to rely on along the pipeline route, with poor traffic conditions and adverse weather conditions. The pipeline is susceptible tosafety hazardscaused by geological conditions, weather conditions, the pipeline body, construction and other factors during construction and after commissioning. In view of the many challenges in the construction and operation of long-distance oil and gas pipelines in mountainous terrain, the corresponding measures to ensure the intrinsically safe operation of pipelines in mountainous terrain are discussed in terms of early project phase survey and final selection of pipeline routes, finalization of pipeline material performance index, welding of piping section with different wall thickness, specific design and construction requirements at interfaces of alternating soft and hard ground strata, layout of pipelines in mountainous areas, pipeline stabilization measures and subsequent pipeline surveillance and monitoring in operation phase.
